| Item | Unit | RP903 |
| Basic paving width | m | 3 |
| Max paving width | m | 9 |
| Max paving thickness | mm | 320 |
| Paving speed | m/min | 0~18 |
| transport speed | Km/h | 0~2.8 |
| feed capacity | t/h | 700 |
| Hopper capacity | t | 14 |
| Gradient ability | % | 20 |
| Smoothness | mm/3m | ≤1.5 |
| slope leveling tolerance | % | ±0.02 |
| Engine type | / | BF6M1013ECP |
| Rated output | Kw/rpm | 150/2000 |
| Fuel tank | L | 300 |
| Generator output | Kw | 30 |
| Total weight | t | 24.5~29.0 |
| dimensiont | mm | 7150*3000*3950 |
